Forged Rigging Components G80 Omega Connection Link
The G80 Omega Link is a high-strength oblong-shaped master link used as a primary connection point in chain sling assemblies.
Manufactured from quenched and tempered alloy steel, this component is designed to withstand heavy loads while maintaining structural integrity. Its omega (pear-shaped) design allows for optimal load distribution and compatibility with hooks, sub-links, and lifting chains.
Technical Specifications
| SIZE(MM) | WLL(T) | BL(T) | A | B | D | H | L | WEIGHT(KG) |
| 6-8 | 1.12 | 4.48 | 8 | 41 | 20.5 | 25 | 52 | 0.12 |
| 7/8-8 | 2 | 8 | 10 | 52 | 23.5 | 35 | 68.5 | 0.22 |
| 10-8 | 3.2 | 12.6 | 12 | 62 | 31.5 | 40.5 | 81 | 0.36 |
| 13-8 | 5.3 | 21.2 | 15 | 81 | 41 | 54 | 108 | 0.71 |
| 16-8 | 8 | 32 | 19 | 99 | 49.5 | 64 | 126 | 1.3 |
| 20-8 | 12.5 | 50 | 23 | 118 | 58 | 75.6 | 152 | 2.2 |
Why Choose an Omega Link?
Compared to standard round or connecting links, the Omega Link offers:
- Better load alignment and balance
- Increased connection space for multiple sling legs
- Improved safety in multi-leg lifting systems
Its shape makes it especially suitable for master link assemblies, where multiple chains or fittings need to be connected securely.
