YS Type Shackle Beam Clamp: The Ultimate Versatile Anchor for Multi-Angle Lifting
The YS Type Shackle Beam Clamp is designed for professionals who require a fast, secure, and highly portable method of creating an overhead anchor point. Whether you are suspending a chain hoist, securing a pulley system, or managing complex cargo lashing, the YS series provides a reliable connection to I-beams and H-beams in seconds.
Technical Specifications
Our YS series is available in capacities ranging from 1 Ton to 10 Tons, meeting the demands of most light-to-medium industrial applications.
| Model Number | Rated Capacity (WLL) | Flange Width Range (mm) | Net Weight (kg) | Proof Load (kN) | Safety Factor |
| YS-1 | 1.0 Ton | 75 – 230 | 3.8 | 12.3 | 4:1 |
| YS-2 | 2.0 Ton | 75 – 230 | 5 | 24.5 | 4:1 |
| YS-3 | 3.0 Ton | 80 – 320 | 9 | 36.8 | 4:1 |
| YS-5 | 5.0 Ton | 90 – 310 | 11 | 61.3 | 4:1 |
| YS-10 | 10.0 Ton | 90 – 320 | 18.6 | 122.5 | 4:1 |
Applications
YS type shackle clamps are ideal for:
- Horizontal steel plate lifting
- Sheet metal transportation
- Steel fabrication workshops
- Shipbuilding industry
- Warehouse material handling
- Construction rigging operations
